Zephyr West tips and tricks

by Noah Pendleton

The Zephyr west tool is a powerful workspace manager, but it is admittedly pretty feature-rich: there’s a lot of functionality buried inside that tool!

I thought it would be interesting to share a few tips and tricks that I use with west to make my Zephyr development workflow a little smoother.

Managing SDKs with west sdk

West has a built-in command for managing Zephyr SDKs:

# install a specific SDK version and target toolchain
west sdk install --version 0.17.4 -t arm-zephyr-eabi

You can install just the toolchain(s) you actually need, rather than pulling down the full SDK bundle. Some other useful targets:

  • riscv64-zephyr-elf
  • xtensa-espressif_esp32_zephyr-elf

Run west sdk list to see what’s available, and west sdk install --help for the full set of options.

What’s awesome is if you run this from a west workspace containing a zephyr project, west sdk install will match the zephyr/SDK_VERSION value, so you’ll get a matching SDK version, ezpz!

  --version [SDK_VER]   version of the Zephyr SDK to install. If not specified,
                        the install version is detected from
                        ${ZEPHYR_BASE}/SDK_VERSION file.

This is covered in more depth in Practical Zephyr - West workspaces (Part 6), definitely worth a read if you haven’t already.

Limiting clone depth with clone-depth

If you’re working with large repositories or frequently initializing new workspaces, you can add clone-depth to projects in your west manifest to speed things up considerably:

# west.yml
manifest:
  projects:
    - name: some-large-repo
      url: https://github.com/example/some-large-repo
      clone-depth: 1

Full manifest reference: https://docs.zephyrproject.org/latest/develop/west/manifest.html#projects

Note: I’m not sure whether clone-depth is respected for projects that are pulled in transitively via import. Worth verifying for your particular workspace setup.

Limiting what west update imports

By default, if you import a project’s manifest (e.g., Zephyr’s west.yml), west will clone all of its listed dependencies recursively. Zephyr has a lot of them, and a naive west update can easily pull down gigabytes worth of repos you don’t need.

Two manifest options that help a lot here:

name-allowlist — Only import the named projects from the upstream manifest:

# west.yml
manifest:
  projects:
    - name: zephyr
      url: https://github.com/zephyrproject-rtos/zephyr
      revision: v4.3.0
      import:
        name-allowlist:
          - cmsis
          - hal_nordic
          - mbedtls

This is Option 3 in the manifest docs and is probably the most useful thing you can do to keep workspace initialization fast.

path-prefix — Put all imported projects under a common subdirectory instead of the workspace root. Keeps things tidy:

import:
  path-prefix: deps
  name-allowlist:
    - cmsis
    - hal_nordic

With the above, imported repos land under deps/ rather than scattered at the top level. The Practical Zephyr - West workspaces article walks through a full working example of both of these together.

Caching west update fetches

If you clone west workspaces frequently (e.g., when testing unfamiliar projects), git fetch traffic can add up quickly. West supports a reference cache to share object storage across workspaces:

west config --global update.auto-cache ~/.cache/west

With auto-cache, west will automatically populate and use a cache directory, so subsequent west update calls in new workspaces can resolve most objects locally instead of hitting the network.

There are a few other useful update.* config options worth looking at in the reference: https://docs.zephyrproject.org/latest/develop/west/config.html#built-in-configuration-options

Aliases

West supports user-defined command aliases, similar to git aliases. These are great for shortening workflows you run constantly. From the docs:

west config --global alias.run "build --pristine=never --target run"
west config --global alias.menuconfig "build --pristine=never --target menuconfig"

After that, west run and west menuconfig just work. The alias docs have more examples: https://docs.zephyrproject.org/latest/develop/west/alias.html#examples

West extensions

West extensions let projects (or your own local tooling) add custom subcommands to west. This is useful when you want project-specific tooling to feel like a first-class citizen in your workflow rather than a separate script (it’s especially nice for discoverability, since everything is available from west --help).

It’s useful when the commands you need don’t fit into the normal build/flash/debug/attach workflow provided by the Zephyr SDK’s own extension commands, and aliases are insufficient.

A quick example: we add the following files/snippets to our manifest repo:

west.yml:

manifest:
  self:
    # register this repo's west extensions
    west-commands: scripts/west-commands.yml

scripts/west-commands.yml:

west-commands:
  - file: scripts/west_extensions.py
    commands:
      - name: project-hello
        class: ProjectHello
        help: sample Project west extension command

scripts/west_extensions.py:

from textwrap import dedent

from west.commands import WestCommand


class ProjectHello(WestCommand):
    def __init__(self):
        super().__init__(
            "project-hello",  # gets stored as self.name
            "",  # ignored self.help, will not be required by future west versions
            description=dedent(
                """
            Sample Project west extension command.
            """
            ),
        )

    def do_add_parser(self, parser_adder):
        parser = parser_adder.add_parser(self.name, description=self.description)

        levels = ["dbg", "inf", "wrn", "err"]
        parser.add_argument(
            "-l",
            "--level",
            default="inf",
            choices=levels,
            help="log level for the message (default: %(default)s)",
        )
        parser.add_argument("message", help="message to print")

        return parser  # gets stored as self.parser

    def do_run(self, args, unknown):
        log_fn = {
            "dbg": self.dbg,
            "inf": self.inf,
            "wrn": self.wrn,
            "err": self.err,
        }[args.level]

        self.inf(f"[{self.name}] log level: {args.level}")
        log_fn(f"[{self.name}] message: {args.message}")

Now the new extension shows up in west --help:

extension commands from project manifest (path: blahblah):
  project-hello:        sample Project west extension command

And we can run it:

❯ west project-hello --level err 'Hello!'
[project-hello] log level: err
ERROR: [project-hello] message: Hello!

The Zephyr reference goes through the details of how to do this: https://docs.zephyrproject.org/latest/develop/west/extensions.html#west-extensions

Reducing what west update fetches

For day-to-day development you often don’t need the full history of every dependency. You can speed up west update significantly with a couple of flags:

west update --narrow --fetch-opt=--depth=1
  • --narrow tells west to only fetch the specific revision referenced in the manifest, rather than fetching all refs from the remote.
  • --fetch-opt=--depth=1 passes --depth=1 to the underlying git fetch, giving you a shallow clone with just the tip commit.

Together these can dramatically cut down network traffic and disk usage, especially on first initialization of a large workspace.

Use git fetch --unshallow on a module to convert a shallow clone to a full one later- this is useful if you need the full history (eg bisecting) or want to make a contribution upstream!

Resolving the manifest to exact SHAs

West manifests typically reference branches or tags, which can drift over time. To capture a fully-resolved snapshot with exact commit SHAs — useful for reproducible builds or auditing — use:

west manifest --resolve

The output is a valid west manifest with every project pinned to a specific revision:

manifest:
  group-filter:
    - -babblesim
    - -optional
    - -testing
  projects:
    - name: canopennode
      url: https://github.com/zephyrproject-rtos/canopennode
      revision: dec12fa3f0d790cafa8414a4c2930ea71ab72ffd
      path: modules/lib/canopennode
      groups:
        - optional
    - name: chre
      url: https://github.com/zephyrproject-rtos/chre
      revision: c4c2f49fdcaa2fed49eb1db027696a5734a010d2
      path: modules/lib/chre
      groups:
        - optional
  # ...

You can redirect this into a west.lock.yml (or similar) and commit it alongside your manifest so that anyone cloning the workspace gets exactly the same tree.

See anything you'd like to change? Submit a pull request or open an issue on our GitHub

References

Noah Pendleton is an embedded software engineer at Memfault. Noah previously worked on embedded software teams at Fitbit and Markforged.
